| 配置 | 参数 |
| Processor Series | Kirin |
| SoC | Hisilicon Kirin 970 |
| CPU | ARM Cortex-A73×4 and Cortex-A53×4 |
| GPU | ARM Mali-G72 MP12 |
| AI | edicated Neural-network Processing Unit (NPU) |
| Memory | 6GB LPDDR4 SDRAM |
| Storage | 64GB UFS flash storage
Micro SD card slot
PCIE Gen2 on M.2 M Key connector |
| Wireless | WiFi(2.4 -and 5-GHz dual band with two antennas)
Bluetooth 4.1
GPS, Glonass |
| USB | 1 x USB 2.0 type C(OTG 1 x USB 2.0 (host only) |
| Display | 1 x HDMI1.4 (Type A -full)
1 x 4L - MIPI DSI
HDMI outout up to FHD 1080P |
| Video | MPEG2@80Mbps, MPEG4@50Mbps, H264@240Mbps, H265@160Mpbs, VP8@100Mbps, VP9@120Mbps |
| Audio | HDMI Output |
| Camera | 1 x 4-lane MIPI CSI
1 x 2-lane MIPI CSI |
| Display | 1 x HDMI1.4 (Type A -full)
1 x 4L - MIPI DSI
HDMI outout up to FHD 1080P |
| Expansion Interface | 40 pin low speed expansion connector:+1.8V, +5V, DC power, GND, 2UART, 2I2C,SPI,I2S,12*GPI 60 pin high speed expansion connector:4L-MIPI DSI, I2C x2, SPI(48M),USB 2.0,2L +4LMIPI CSI |
| CAN | Implements CAN V2.0B at 1Mb/s |
| Ethernet | Gigabit Ethernet |
| LED | 1 x WiFi activity LE 1 x BT activity LED 4 x User LEDs |
| Button | Power Button : Button Power on /off & Reset the system |
| Power Source | Recommend a 12V@2A adaptor with a DC pulg which has a 4.75mm outer diameter and 1.7mm center pin with standard center -positive(EIAJ-3 Compliant) |
| OS Support | AOSP/LINUX |
| Appearance characteristic | 100mm × 85mm × 10mm |
