Atlas 200 Developer Kit

Based on Huawei Ascend series AI processors and the mainstream heterogeneous computing components in the industry,

via a variety of product forms such as modules, boards, small stations and all-in-one machines,

a scenario AI Infrastructure Solution for "end, edge and cloud" is created,

which can be widely used in "safe city, intelligent transportation, intelligent medical treatment, AI reasoning" and other fields

Product Highlights

01 Small Body Huge Energy
Based on Huawei Ascend AI processor, it can support 16 Channel HD video real-time analysis with a small size of half a credit card
02 Intelligent End & Side Device
For the deployment of end devices such as cameras and UAVs, and side devices such as intelligent small stations, the TDP power consumption is only 9.5W
03 Open Ecology
Support the industry mainstream framework, easy-to-use code migration and model transformation tools, and build an open industry ecosystem with ISV by flexible cooperation
04 Highly Integrated
Based on Huawei Ascend AI processor, it integrates rich peripheral interfaces and mind Studio software to facilitate developers to quickly familiarize themselves with the development environment
05 Simple Use Software Environment
Friendly programming interface of Mind Studio, with graphic debugging ability, can automatically manage offline models and provide simulation environment

Application Scenarios

Video Camera
Robot
Image Analysis

: Video Camera

: Robot

: Image Analysis

Product Parameters

Configuration	Parameter
AI Processor	2 DaVinci Cores CPU: Eight-core A55，max 1.6GHz
AI Computing Power	Performance of multiplication and addition：8TFLOPs/FP16,16TOPS/INT8 Support 16TOPS、8TOPS、4TOPS computing power allocation
Memory	LPDDR4x,128bit Capacity 8GB/4GB Interface rate 3200 Mbps
ECC	Support ECC
Storage	Built-in SPI flash. Capacity 64MB External MMC interface, support: 1. Emmc4.5 particles, the highest mode SDR50, maximum capacity 64GB 2. SD3.0 card, the highest mode SDR50, maximum capacity 2T
Codec capability	Support H.264 Decoder hardware decoding, 16 channels 1080p 30FPS (2 channels 3840 × 2160 60FPS), YUV420 Support H.265 Decoder hardware decoding, 16 channels 1080p 30FPS (2 channels 3840 × 2160 60FPS), YUV420 Support H.264 Encoder hardware decoding, 1 channel 1080p 30FPS, YUV420 Support H.265 Encoder hardware decoding, 1 channel 1080p 30FPS, YUV420 JPEG decoding capacity 1080p 256FPS, decoding capacity 1080p 64FPS, maximum resolution: 8192 × 8192 PNG decoding capacity 1080p 48FPS, maximum resolution: 4096 × 409
High Speed Interface	PCIe3.0×4 lane，Support RC or EP mode RGMII:1 PORT USB 2.0/USB 3.0:1 Lane
Serial Bus	UART:2PORT I2C:3PORT SPI:3PORT(SPI3 and I2C2、UART1 Signal multiplexing) Note: I2C interface cannot be used when Atlas 200 is used as a slave device
Other Interfaces	eMMC&SD:1PORT Atlas 200 Power on signal × 1 Atlas 200 Reset signal × 1 PWM×2 GPIO×4
Interface Specification	144pin BTB connector Compatible with 4.3mm, 6mm
Power Consumption	Working voltage：3.5V~4.5V，3.8V is recommended for typical value Typical power consumption: 9.5W (16TOPS)
Structure Size	52.6mm×38.5mm×8.5mm Note: Atlas 200 connector model is fixed, users can choose different plug to adapt different Atlas 200
Weight	30g
