HiHope Infrared Thermometer（HH-SVTM200）

Based on the dual light artificial intelligence camera, achieves the rapid detection of human body temperature,

with the characteristics of high temperature sensitivity, non-contact, automatic face recognition/automatic recording,

intuitive thermal image, wide detection range, fast speed, no interference with the measured target, safety in use and so on.


Product Highlights

01
AI algorithm is used to automatically recognize the maximum temperature of human face, and the temperature of the tested person can be quickly detected within 0.5 seconds. The temperature resolution can reach ±0.2℃ (33℃ ~ 42℃)
02
Testing personnel can obtain accurate data in the monitoring room to avoid contact with the tested personnel
03
The tested personnel do not need to stay or stand in the designated place, which is convenient for data collection
04
Can recognize multiple targets and target temperature at one time, simultaneously capture and upload datas
05
AI fuzzy algorithm can be used for face recognition of people wearing masks
06
AI algorithm automatic tracking search, automatic alarm, achieves 24-hour all-weather monitoring
07
Alarm given immediately in case of suspicious fever patients to effectively prevent cross infection between operators and stream of people
08
To identify the fever population efficiently and quickly, achieves early detection and isolation, and control the further spread of the epidemic

矩形.png Technical Parameters of Temperature Measuring Gun

Thermal Infrared
Sensor	Uncooled infrared focal plane sensor
Array Size	384×288 pixel
Working Wave Band	8～14μm
Accuracy	±0.2℃ under the condition of Circumstance temperature10~35℃ (Including Blackbody)
Measuring Range	33℃～+42℃
Intelligent Detection of Temperature Measuring Point	Up to 5 movable temperature measuring points can be selected
Visible light
Sensor	1/2.8”SONY Exmor CMOS
Array Size	1920×1080 pixel
Major Function	Automatic aperture, Automatic white balance, Backlight compensation, Automatic shutter and Automatic/manual conversion at low irradiance (color/black and white)
Code Mode	H.264 BP/MP/HP/MJPEG Code (Algorithm optional)
Intelligence	Supports intelligent algorithms such as face detection, face recognition and masking face recovery
Amalgamate	Supports alignment of visible and infrared scene and target matching

矩形.png Technical Parameters of Blackbody

矩形.png System Parameters

Configuration	Parameter
Temperature Range	20℃～60℃
Array Size	±0.2℃(33℃～42℃) ±0.5℃(43℃～60℃) ±0.5℃(20℃～32℃)
Video Compression	H.265 H.264 MJEP
Measuring Range	3m ~ 15m (Customized version with variable distance)
Image Process	Nonuniformity Correction 3D Noise Reduction Digital Image Enhancement
RAM	DDR4 4G
